STOP SHEET 455 195

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth STOP SHEET (3842545660) is a robust and versatile safety component designed for use with conveyor systems. This stop sheet serves as a protective cover and end plate, enhancing the safety of working areas by preventing accidental contact with moving parts. It is specifically engineered to be compatible with curves, diverters, and junctions within conveyor units. The product can be ordered separately for these units, although it may come included in the scope of delivery for certain applications. The STOP SHEET is easily installed between conveyor rollers using spring elements, ensuring a secure fit without the need for complex tools or procedures. Users should note that these protective covers and end plates are not designed to bear weight and should not be walked upon. This model includes special covers tailored for various conveyor section widths and roller spacings, including those at the center of conveyors, transitions, and ends. The package comes with an end plate for the left drive side (D) and an equivalent part for the right drive side (E). Additionally, lateral guide covers (F) are available to protect the sides of the conveyor. Installation requires thread-forming screws DIN EN ISO 1478 – ST4.2x9.5-C-H (G), which customers must source independently. Each end plate requires two screws, while each lateral guide cover necessitates four screws. Furthermore, spring elements (H), which are necessary for attaching each end plate securely to the system, are included in this package. For finishing touches, cap covers (J) are provided to seal open profile ends at each section end of the conveyor unit. These caps ensure a clean look while also preventing debris from entering the profiles. Constructed from galvanized steel, this STOP SHEET is built to withstand industrial conditions while maintaining its structural integrity over time. Its design caters to a variety of track widths and roller spacings within Bosch Rexroth's modular conveyor system range.
