DAMPER DA 5/1000

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth DAMPER DA 5/1000 (3842545130) is a pneumatic damper designed to provide damped stopping of an accumulating workpiece pallet during infeed, ensuring smooth operation and reduced impact within material handling systems. This damper offers steplessly adjustable damping, allowing for precise control over the deceleration of pallets to suit various system requirements. Additionally, it features a self-adjusting mechanism that adapts to different loads referenced in the technical data. The DA 5/1000 model is specifically engineered to be integrated into workpiece pallet systems. It operates by extending pneumatically into the damping position as a workpiece pallet is infeeded onto the main section of a conveyor. The damper then retracts after being pushed into its end position by the incoming pallet, allowing for seamless transition onto the main conveyor section. For optimal performance, this damper requires a specific range of compressed air connections with maximum and minimum pressures detailed in its specifications. The product group ID and packaging unit indicate that it comes as a set, which includes fastening materials for installation on conveyor sections and a push-in air connection measuring mm in diameter. In terms of weight considerations, this damper accommodates workpiece pallet total weights (mG), and its own mass (m) is noted within the specifications. The nominal speed at which it operates is also provided, ensuring compatibility with various system speeds. Included within the scope of delivery are all necessary installation components. While not assembled upon delivery, recommended and required accessories such as lateral guide covers are suggested to ensure proper function and safety. Overall, the Bosch Rexroth DAMPER DA 5/1000 offers an efficient solution for controlled damping within automated material handling systems.
