BASE BODY WT5 / 845X845
Manufacturer: Bosch Rexroth
Material #: 3842545092
Model : BASE BODY WT5 / 845X845
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth BASE BODY WT5 / 845X845 (3842545092) is a robust and versatile base pallet designed to interface seamlessly with transfer systems and carrying plates equipped with workpiece fixtures. This base body is engineered to withstand the highest loads, ensuring stability and reliability in demanding applications. Its standard size and optimized contours are specifically crafted for smooth movement through curves, enhancing the efficiency of material handling processes.
Incorporating stop gates on both the interior and exterior surfaces along the longitudinal conveyor direction, this model provides added control over workpiece positioning, contributing to precise operations. The BASE BODY WT5 / 845X845 is also compatible with mobile data tags from Bosch Rexroth's ID RFID system, allowing for advanced tracking and data management capabilities.
Constructed from PE-UHMW material that is ESD-compatible, it ensures durability as well as compliance with static-sensitive environments. The product has a substantial length of 845 mm and a weight of 8.9 kg, balancing size and manageability. It is delivered unassembled; however, an attachment kit is available for purchase separately to facilitate easy assembly. The kit includes rollers, roller pins, damping elements, and sensor plates necessary for full functionality.
For additional precision in setting up the system, a positioning bushing kit can be acquired along with a carrying plate to complete the setup. Overall, the Bosch Rexroth BASE BODY WT5 / 845X845 (3842545092) is an essential component for users seeking a high-performance base pallet solution for their conveyor systems or automated material handling setups.
$861.35 USD
Availability: 4 In Stock
Available for immediate shipmentQty: Delivered as early as November 12, 2024 when ordered in
