HINGE AL 20/30

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth HINGE AL 20/30 (3842544526) is a high-quality hinge designed for versatile applications. This diecast aluminum, nickel-plated hinge is capable of being mounted on solid surface elements, offering a robust and reliable solution for connecting profiles. Its construction is suitable for clean room conditions due to its abrasion-resistant guide bushings, ensuring minimal particulate generation during operation. The HINGE AL 20/30 is part of Bosch Rexroth's product group ID and comes in a packaging unit that includes all necessary fastening materials for installation. It features an ESD yes designation, indicating it is safe for use in electrostatically sensitive environments. The hinge can handle a maximum force (Fmax), although the exact value isn't specified in the provided information. For assembly, this hinge comes with x countersunk screw DINMX, x T-nut groove M, x countersunk screw DINMx, and x T-nut groove M. These components facilitate secure mounting to profiles with slot dimensions specified by the manufacturer. The dimension A and dimension B are not detailed but are intrinsic to the hinge's design, contributing to its overall weight and structural integrity. Overall, the Bosch Rexroth HINGE AL 20/30 offers a conductive version that meets stringent operational standards and is ideal for constructing stable connections in various applications where cleanliness and electrostatic discharge control are required.
