CONNECTOR 0°-90°

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth CONNECTOR (3842541178) is a versatile and robust component designed for the EcoShape tubular framing system. This die-cast zinc connector facilitates the construction of swiveling applications by allowing for easy adjustment within a 0°-90° range, making it ideal for creating dynamic and flexible structures. The model includes a D connector and a DL swivel bearing that supports axial shifting along the DL or DL, N round tube, with the retaining ring ensuring a secure end position. This product is particularly well-suited for self-assembly, as it comes with an L mm long DL swivel bearing that can be trimmed to the desired length, a D bushing to fit standard tubes securely, and a DL retaining ring to lock components in place. An additional thread feature allows for flexible bracket adjustment to meet various application requirements. The CONNECTOR is part of the EcoShape tubular framing system components and boasts an ESD yes rating, indicating its suitability for electrostatic discharge sensitive environments. The scope of delivery includes fastening material comprising x cylinder head screw ISO Mx,x and hexagon nut DIN M ISO , ensuring you have all necessary hardware for immediate installation. With its weight of . kg, this product offers both lightweight construction and durability. Designed with efficiency in mind, this Bosch Rexroth CONNECTOR simplifies assembly while providing strong and reliable connections within your framing systems. Whether you're constructing workstations, flow racks, or custom machinery frames, this connector ensures your structures are easily adjustable and securely held in place.
