LIFT-ROTATE UNIT HD2 B320*LT320 180 90

Manufacturer: Bosch Rexroth

Material #: 3842525870

Model : LIFT-ROTATE UNIT HD2 B320*LT320 180 90


***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LIFT-ROTATE UNIT HD2 B320*LT320 180 90 (3842525870) is a versatile and robust component designed for precise handling and orientation of workpiece pallets within automated conveyor systems. This unit features the capability to rotate workpieces on the Z axis by either 90° or 180°, providing flexibility in aligning products during manufacturing or assembly processes. The HD2 lift rotate unit is engineered to accommodate a maximum permitted total mass moment of inertia of 0.65 kgm², ensuring stability and reliability even when handling heavier loads. One of the key functionalities of this model is its ability to lift workpiece pallets either 40 mm or 90 mm above the transportation level. The 40 mm version is ideal for rotating pallets directly over the conveyor section, keeping the process streamlined and efficient. For applications where additional clearance is needed—such as when side-mounted components like identification and data storage modules are present—the 90 mm lift variant provides the necessary space to avoid interference during rotation. The design of the HD2 lift rotate unit allows for seamless integration into circulation systems that lack curves, maintaining consistent orientation throughout operations. This ensures that each workpiece pallet can be processed with its front side leading, which can be critical for certain applications requiring specific orientations for operations like scanning, labeling, or additional processing steps. Overall, Bosch's HD2 B320*LT320 lift rotate unit offers an effective solution for automated material handling systems where precision in positioning and orientation of workpieces is paramount. Its robust construction and reliable performance make it a valuable asset in streamlining production lines and enhancing operational efficiency.

$5,662.37 USD

More are expected on February 3, 2025
  Add to Cart

Status: This product is temporarily out of stock.


Qty: Delivered as early as February 3, 2025 when ordered in
