LIFT-ROTATE UNIT HD2 B320*LT240 180 90

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LIFT-ROTATE UNIT HD2 B320*LT240 180 90 (Material Number 3842525866) is a versatile and efficient component designed for the precise manipulation of workpiece pallets within automated material handling systems. This lift-rotate unit boasts the capability to turn workpiece pallets at angles of either 90° or 180° on the Z axis, allowing for optimal orientation and processing of items as they move through the production line. It features two distinct lifting options, with the ability to elevate pallets either 40 mm or 90 mm above the transportation level. The 40 mm variant is particularly well-suited for rotating pallets directly over conveyor sections, while the 90 mm lift version accommodates side-mounted components on pallets, such as identification and data storage modules. Engineered to handle a maximum total mass moment of inertia of up to 0.65 kgm², this unit ensures smooth and stable operation even when managing heavier loads. Its design permits work on the HD2 without the need for additional applied force, streamlining processes and enhancing workplace safety. The unit's integration into circulation systems is especially beneficial in scenarios where curves are absent from conveyor layouts, ensuring that each workpiece maintains its proper leading edge throughout transportation. Overall, the Bosch LIFT-ROTATE UNIT HD2 B320*LT240 180 90 represents a sophisticated solution for manufacturing environments seeking to optimize their handling and orientation of goods within automated systems. Its robust construction and precise control mechanisms make it an indispensable asset for facilities aiming to maximize efficiency and maintain consistent product flow.
