LIFT-ROTATE UNIT HD2 B320*LT160 180 40

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LIFT-ROTATE UNIT HD2 B320*LT160 180 40 (Material Number 3842525863) is a robust and versatile component designed for precise handling and orientation of workpiece pallets within automated conveyor systems. This unit features a turning angle on the Z-axis of either 90° or 180°, offering flexibility in the manipulation of pallets to ensure they are always facing the correct direction. The HD2 lift rotate unit can elevate workpiece pallets either 40 mm or 90 mm above the transportation level, making it an ideal solution for systems that require direct turning above the conveyor section or have side-mounted components such as identification and data storage modules. The unit's capability to lift at two different heights allows for customization based on specific application requirements. The lower 40 mm lift is perfect for operations with minimal clearance, while the higher 90 mm lift accommodates additional attachments on the pallets. With a maximum permitted total mass moment of inertia of 0.65 kgm², this lift-rotate unit can handle substantial loads while maintaining its efficiency and reliability. Designed to integrate seamlessly into circulation systems without curves, the Bosch LIFT-ROTATE UNIT HD2 ensures consistent front-facing orientation of workpieces throughout the production process. This feature is particularly beneficial in applications where orientation impacts subsequent automated processes or quality control inspections. The ease of use and maintenance-free operation make it an excellent addition to any high-performance manufacturing or assembly line looking to optimize workflow and increase productivity with minimal manual intervention.
