LIFT-ROTATE UNIT HD2 B240*LT160 180 90

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LIFT-ROTATE UNIT HD2 B240*LT160 180 90 (3842525856) is a high-precision handling module designed to rotate workpiece pallets on conveyor systems. It is particularly useful in applications where the orientation of the pallet is crucial, as it can turn pallets either 90° or 180° on the Z axis. This functionality ensures that items are always facing forward without requiring curves in the conveyor system. The unit has two lifting options to accommodate different setups: a 40 mm lift for instances where the pallet needs to be turned directly above the conveyor section, and a 90 mm lift for situations where side-mounted components, such as identification and data storage modules, are present on the workpiece pallet. The choice of lift height provides flexibility in integrating the unit into various system configurations. With its robust design, the LIFT-ROTATE UNIT HD2 B240*LT160 180 90 can handle a maximum total mass moment of inertia of 0.65 kgm², ensuring stable and reliable operation even with heavier loads. The unit's ability to individually actuate rotational direction for each workpiece pallet enhances its adaptability to specific process requirements. This lift rotate unit is an integral component for streamlining material handling processes in automated environments, offering both efficiency and precision. Its design allows for seamless integration into existing conveyor systems while providing essential orientation control of workpiece pallets during transport.
