LIFT-ROTATE UNIT HD2 B160*LT240 180 90

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LIFT-ROTATE UNIT HD2 B160*LT240 180 90 (Material Number 3842525852) is a robust and efficient solution for the orientation and positioning of workpiece pallets within automated conveyor systems. This unit is designed to lift and rotate workpieces with precision, featuring turning angles on the Z-axis of either 90° or 180°, which can be individually actuated to accommodate the specific orientation requirements of each pallet. The LIFT-ROTATE UNIT HD2 is capable of lifting workpiece pallets either 40 mm or 90 mm above the transportation level. The 40 mm lift version is particularly useful for rotating pallets directly above the conveyor section, making it an ideal choice for systems with limited vertical clearance. In contrast, the version with a 90 mm lift is designed to handle situations where side-mounted components on the pallet, such as identification tags or data storage modules, necessitate additional space to avoid interference during rotation. With a maximum permitted total mass moment of inertia of 0.65 kgm², this unit ensures smooth and stable handling of payloads without requiring additional force during operation. It contributes significantly to streamlining processes in circulation systems that lack curves by maintaining consistent orientation throughout the transport journey. This lift-rotate unit from Bosch is an essential component for enhancing efficiency in automated material handling applications where precise control and positioning of workpiece pallets are critical.
