LIFT-ROTATE UNIT HD2 B160*LT160 90 90

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LIFT-ROTATE UNIT HD2 B160*LT160 90 90 (3842525849) is a robust and efficient solution designed to optimize the orientation of workpiece pallets in automated conveyor systems. This unit features the capability to rotate workpiece pallets on the Z axis by precise angles of either 90° or 180°, accommodating various process requirements and ensuring that each pallet is aligned correctly for subsequent operations. The HD2 lift rotate unit can individually actuate the rotational direction for each pallet, providing flexibility and control in handling different items. Equipped with two lifting options, the unit can elevate workpiece pallets by either 40 mm or 90 mm above the transportation level. The 40 mm version is ideal for rotating pallets directly over conveyor sections without interfering with adjacent processes. In contrast, the higher 90 mm lift version caters to scenarios where side-mounted components on the pallet, such as identification tags or data storage modules, necessitate additional clearance. With a maximum permitted total mass moment of inertia of 0.65 kgm², this lift rotate unit ensures stable and secure handling of workpieces during rotation and lifting movements. Its design allows for seamless integration into circulation systems lacking curves by maintaining consistent orientation throughout the transport process. Additionally, operating the HD2 does not require any additional force application, which simplifies usage and enhances workflow efficiency. Overall, this Bosch lift rotate unit is a valuable asset in any production line where precise orientation and positioning of workpieces are critical for maintaining a streamlined operation. Its thoughtful design ensures reliability and adaptability in various industrial applications without compromising performance or safety.
