ANVIL PLATE HP2/K 240X240
Manufacturer: Bosch Rexroth
Material #: 3842242377
Model : ANVIL PLATE HP2/K 240X240
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth ANVIL PLATE HP2/K 240X240 (3842242377) is a robust and precision-crafted component designed for use with the PE 2/XP positioning unit. This anvil plate is part of Bosch's BG 2 series, with dimensions of 240mm by 240mm, providing a stable and flat surface for various applications. It is specifically tailored to support the precise positioning tasks required in complex assembly or manufacturing processes where accuracy and repeatability are paramount. The anvil plate's construction ensures durability and resistance to wear, making it suitable for continuous industrial use. Its compatibility with the PE 2/XP positioning unit highlights its role in facilitating fine adjustment and secure holding of workpieces or tools during operation. This integration enhances the functionality of the positioning unit, leading to improved efficiency and productivity in automated systems. As a genuine Bosch replacement part, the ANVIL PLATE HP2/K guarantees compatibility and performance that meets the rigorous standards set by one of the industry leaders in automation technology.
$296.33 USD
Availability: 3 In Stock
Available for immediate shipmentQty: Delivered as early as December 26, 2024 when ordered in
Anvil plate drilling plan
|
Workpiece pallet size |
Workpiece pallet size |
Type |
b |
l |
x |
y |
|
bWT (mm) |
lWT (mm) |
|
(mm) |
(mm) |
(mm) |
(mm) |
|
160 |
160 |
a1 |
80 |
80 |
15 |
40 |
|
a2 |
80 |
80 |
65 |
40 |
||
|
160 |
240 |
a1 |
80 |
160 |
15 |
40 |
|
a2 |
80 |
160 |
145 |
40 |
||
|
240 |
160 |
a1 |
80 |
160 |
15 |
40 |
|
a2 |
80 |
160 |
145 |
40 |
||
|
240 |
240 |
a1 |
160 |
160 |
20 |
80 |
|
a2 |
160 |
160 |
140 |
80 |
||
|
240 |
320 |
a1 |
160 |
240 |
20 |
80 |
|
a2 |
160 |
240 |
220 |
80 |
|
No. |
3842242375 | 3842242376 | 3842242377 | 3842242378 | ||
|
Max. total weight of workpiece pallet |
mG |
kg |
20 | 30 | 30 | 30 |
|
Size |
BG |
BG 1 | BG 2 | BG 2 | BG 2 |
Drilling plan for upper part of PE 2/XP (BG 1)
Drilling plan for upper part of PE 2/XP (BG 2)
