POSITIONING UNIT PE 2/XP BG2
Manufacturer: Bosch Rexroth
Material #: 3842242351
Model : POSITIONING UNIT PE 2/XP BG2
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth POSITIONING UNIT PE 2/XP (3842242351) is a robust and precise positioning unit designed to handle workpiece pallets with high vertical process force requirements, making it ideal for applications such as press-fit or riveting tasks. This unit is specifically engineered to lift workpiece pallets above the transportation level by approximately 3 mm, ensuring smooth integration into automated processes. It is compatible with WT 2 workpiece pallets and can accommodate larger pallet sizes exceeding 320 x 240 mm.
The PE 2/XP positioning unit stands out for its ability to absorb and manage forces of up to 100 kN/60 kN, which are applied at specific points on the workpiece. The design facilitates direct absorption of these forces, allowing for efficient operation even when the forces are eccentrically applied. To ensure optimal performance, the area where process forces are introduced should be within the surface area of the upper part of the PE 2/XP.
This positioning unit's sophisticated design allows it to be mounted in force cells, offering positive force introduction and enhancing its capability to handle demanding industrial applications. Its specialized configuration permits integration into various manufacturing setups that require precision handling of heavy loads with high process forces. The Bosch Rexroth PE 2/XP positioning unit is a key component for any operation seeking reliable and accurate positioning in conjunction with substantial vertical force application.
$6,974.92 USD
More are expected on February 25, 2025
Status: This product is temporarily out of stock.
Qty: Delivered as early as February 25, 2025 when ordered in
