3WRCBH25VF190M-1X/ZM

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth 3WRCBH25VF190M-1X/ZM (0811402514) is a high-response valve that is designed for block installation with a 3/2 directional symbol, allowing for precise control of fluid flow in hydraulic systems. This valve features a control spool with an anti-rotation feature and control edges that are crafted to servo-type quality, ensuring reliable and accurate operation. With the capability to withstand pressures up to 315 bar, this valve is suitable for demanding applications. Incorporating an inductive position transducer, the 3WRCBH25VF190M-1X/ZM valve offers position-controlled functionality through an external pilot valve and corresponding valve electronics. The pilot line A-X is generally required for its operation, while a dynamic return path (B–Z) can be implemented with sizes 25 and size 50 of this model. This flexibility makes it an ideal choice for electro-hydraulic controls within both production and test systems. The hysteresis of the Bosch 3WRCBH25VF190M-1X/ZM valve is less than 0.1%, which is hardly measurable, indicating extremely precise control capabilities. Additionally, the flow characteristics of the valve are progressive with fine control edges, which allows for smooth and incremental adjustments to fluid flow. Commonly used in the plastic industry at the injection cylinder due to its compact design, this high-response valve excels in applications where quick and accurate responses are critical to system performance. The combination of advanced design features makes it well-suited for sophisticated electro-hydraulic controls that require a high level of precision and reliability.
