ZDRE10VP2X-1X/250YMG24-8Z4M-6

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth ZDRE10VP2X-1X/250YMG24-8Z4M-6 (0811402173) is a sophisticated pilot-operated pressure reducing valve designed for precise system pressure reduction in various hydraulic applications. This 3-way valve in sandwich plate design offers a reliable solution for controlling actuator pressure through its advanced features, including a proportional solenoid, main valve, and control spool. The proportional solenoid adjusts the pressure in channel P1 based on command values, ensuring accurate pressure settings. The valve's functionality is enhanced by its unique construction that enables the connection between channels P2 and P1 to open in the rest position, allowing for effective pressure regulation. The pilot oil is directed through a series of bores and nozzles to the spring chamber and then back to the tank, creating a system that responds dynamically to changes in actuator pressure. With integrated control electronics housed within the unit, this Bosch valve ensures minimal manufacturing tolerance on command value pressure characteristic curves. It also features external control electronics for certain types, further enhancing its adaptability. The design adheres to DIN 24340 form A and ISO 4401 standards with four distinct pressure ratings available. This model is particularly notable for its linear relationship between pressure and command value, indicative of Bosch's commitment to precision engineering. Additionally, it is equipped with various versions (XY, XL, Y, L) to address specific application requirements concerning pilot oil supply and leakage prevention. Overall, the Bosch ZDRE10VP2X-1X/250YMG24-8Z4M-6 presents itself as an integral component for systems requiring controlled reduction of system pressures with high reliability and accuracy. Its design ensures that it can be seamlessly integrated into various hydraulic circuits while maintaining optimal performance levels.
