Axial piston variable motor

Material #: R910987434

$1,600.00

Dual displacement motor with well-tried A10-rotary unit technology Approved for high speeds Long service life High power density Low operating noise Minimum swivel angle can be set externally Swashplate design

Product lead time: 133 days

Add to Cart

Table of values

Size

28 45 63 85

Displacement

Vg max

cm³

28 45 62 87

Vg min

cm³

8 12 16 22

Nominal pressure

pnom

bar

280 280 280 280

Maximum pressure

pmax

bar

350 350 350 350

Maximum speed

at Vg max 1)

nnom

rpm

4700 4000 3300 3100

at Vg min

nmax

rpm

5400 4600 3900 3560

Inlet flow

at Vg max and nnom

qV nom

l/min

131.6 180 205 270

Torque

at Vg max and pnom

M

Nm

125 200 276 387

Weight (approx.)

m

kg

14 18 26 34
1) At least 18 bar required at low pressure side
