Axial piston variable pump
Material #: R902549838
Through drive for mounting of further pumps up to same nominal size Low operating noise Long service life Short control response times Excellent suction characteristics 2 drain ports Swashplate design
Product lead time: 133 days
Quantity in stock: 0
Table of values
|
Size |
18 | 28 | 45 | 71 | 100 | 140 | 45 | 71 | 100 | 140 | |||
|
Version |
Standard | High speed | |||||||||||
|
Displacement |
Vg max |
cm³ |
18 | 28 | 45 | 71 | 100 | 140 | 45 | 71 | 100 | 140 | |
|
Nominal pressure |
pnom |
bar |
280 | 280 | 280 | 280 | 280 | 280 | 280 | 280 | 280 | 280 | |
|
Maximum pressure |
pmax |
bar |
350 | 350 | 350 | 350 | 350 | 350 | 350 | 350 | 350 | 350 | |
|
Maximum speed |
at Vg max |
nnom |
rpm |
3300 | 3000 | 2600 | 2200 | 2000 | 1800 | 3000 | 2550 | 2300 | 2050 |
|
Flow |
at Vg max and nnom |
qV nom |
l/min |
59 | 84 | 117 | 156 | 200 | 252 | 135 | 178 | 230 | 287 |
|
at Vg max and n = 1500 rpm |
qV 1500 |
l/min |
27 | 42 | 68 | 107 | 150 | 210 | |||||
|
Power |
at qV nom and pnom |
P |
kW |
30 | 39 | 55 | 73 | 93 | 118 | 63 | 83 | 107 | 134 |
|
at qV 1500 and pnom |
P 1500 |
kW |
12.6 | 20 | 32 | 50 | 70 | 98 | |||||
|
Torque |
at Vg max and pnom |
M |
Nm |
80 | 125 | 200 | 316 | 445 | 623 | 200 | 316 | 445 | 623 |
|
Weight (approx.) |
m |
kg |
12 | 15 | 21 | 33 | 45 | 60 | 21 | 33 | 45 | 60 | |
