AXIAL PISTON VARIABLE PUMP

A10VO seriesĀ 5x

Material #: R902429240

Through drive for mounting of further pumps up to same nominal size Approved for high speeds Low operating noise Short control response times Large variety of controls High power density Swashplate design

This product is not available. Please call 888-REXROTH to speak to a local distributor who can assist in locating your part or a suitable replacement

Through drive for mounting of further pumps up to same nominal size Approved for high speeds Low operating noise Short control response times Large variety of controls High power density Swashplate design

Table of values

Size

10 18 28 45 60 63 72 85 100

Displacement
geometric, per revolution

Vg max

cm³

10.5 18 28 45 60 63 72 85 100

Nominal pressure

pnom

bar

250 250 250 250 250 250 250 250 250

Maximum pressure

pmax

bar

315 315 315 315 315 315 315 315 315

Maximum speed 1)

at Vg max

nnom

rpm

3600 3300 3000 2600 2600 2600 2600 2) 2500 2300

Flow

at Vg max and nnom

qV nom

l/min

37 59 84 117 156 163 187 212 230

at Vg max and n = 1500 rpm

qV 1500

l/min

15 27 42 68 90 95 108 128 150

Power

at qV nom and pnom

P

kW

16 25 35 49 65 68 77 89 96

at qV 1500 and pnom

P 1500

kW

7 11 18 28 37 39 45 53 62

Torque

at Vg max and pnom

M

Nm

42 71 111 179 238 250 286 338 398

Weight (approx.)

m

kg

8 11.5 14 18 22 22 22 36 36
1) These values are valid at an absolute pressure of 1 bar in suction port S and for the optimum viscosity range νopt
2) Please contact us regarding higher speeds
