R901459599

4WE6E5X/BW120RNVP1Z2

Manufacturer: Bosch Rexroth

Material #: R901459599

Model : 4WE6E5X/BW120RNVP1Z2


***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth 4WE6E5X/BW120RNVP1Z2 (R901459599) is a high-performance directional spool valve designed for controlling the start, stop, and direction of flow in hydraulic systems. This particular model features two solenoid-actuated spool positions without a detent in its deenergized state, meaning there is no defined spool position until energized. The valve operates with wet-pin solenoids that require hydraulic fluid in the pressure chamber to function correctly. Equipped with a manual override, operators can manually adjust the control spool even when the solenoids are not energized. The design includes one or two return springs that reset the control spool to its rest position after de-energization of the solenoids. It should be noted that due to design reasons, internal leakage may occur and potentially increase over the life cycle of the valve. The 4WE6E5X/BW120RNVP1Z2 valve is suitable for use in potentially explosive atmospheres and meets the requirements of the Explosion Protection Directive EU for both mining (IM) and gas environments (IIG). It offers maximum safety with Type of protection Ex ib I Mb / Ex ib II C T Gb according to EN standards. The porting pattern adheres to ISO standards, ensuring compatibility with a wide range of systems. This model also includes throttle inserts ('...B'), which are essential when operating conditions produce flows during switching processes that exceed the performance limit of the valve. With options for wet-pin AC or DC solenoids, electrical connections can be made either individually or via piping connection NPT. The component series X indicates its modern design iteration, capable of handling maximum operating pressures up to bar and maximum flow rates up to l/min, making it a versatile choice for various hydraulic applications within its specified explosion protection parameters.

$2,463.00 USD

Availability:  Unavailable
  Add to Cart

Status: This product is temporarily out of stock.

We have you covered! Place your order today! More are expected on August 19, 2024


Qty: Delivered as early as August 19, 2024 when ordered in

This product is eligible for factory repair.
