PROP PRESSURE CONTROL VALVE -Z ZDREE6VP2-1X/210MG24N9K24F1M

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth ZDREE6VP2-1X/210MG24N9K24F1M (R901366629) is a state-of-the-art industrial hydraulic valve designed for precise pressure reduction and control in hydraulic systems. Engineered to offer reliable performance, this pilot-operated 3-way pressure reducing valve integrates advanced features including a proportional solenoid with integrated electronics for command value-dependent pressure settings. The valve's technical setup is composed of a pilot control valve, a proportional solenoid with control electronics, and a main valve with a main control spool. This configuration enables the ZDREE6VP2-1X/210MG24N9K24F1M to effectively manage the pressure in channel P, ensuring that it corresponds accurately to the input command value. The connection from P to T is opened while blocking the connection from P to A when in an initial position due to the force of the spring on the main control spool. For pressure reduction, the pilot pressure builds up within the control chamber correlating with the command value, facilitating fluid flow from P to A. The design also incorporates a pressure limitation feature that activates if the pressure in port P surpasses the set level, thereby moving the main control spool further left and opening up a connection from P to T which limits the port's pressure. This Bosch Rexroth valve boasts specifications such as an electrical connection via an M12 standard connector pole, CE conformity for electromagnetic compatibility within EU standards, and suitability for various hydraulic fluids like HL, HLP, HLPD, HVLP, HVLPD, and HFC. Additionally, it has a maximum flow rate of 6 liters per minute and operates on a supply voltage of 24 VDC. The sandwich plate or subplate mounting options provide versatility for system integration following ISO standards or NFPA T3.5.1 R2-2002 D03 pattern. Designed for robust industrial applications demanding precise hydraulic control and reliability, this Bosch Rexroth valve is essential for systems requiring accurate pressure regulation and limitation functions.
