DIRECTIONAL SPOOL VALVE KKDER1DA/HN9V

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth KKDER1DA/HN9V (R901070125) is a high-performance directional spool valve, designed for direct operation with solenoid actuation. This screw-in cartridge valve is an integral component for hydraulic systems requiring precise control over the start, stop, and direction of fluid flow. With a maximum operating pressure of 350 bar and a maximum flow rate of 20 l/min, it ensures reliable performance under demanding conditions. The KKDER1DA/HN9V valve features wet-pin DC solenoids that can be rotated for ease of installation and maintenance. Its manual override is concealed, offering an alternative control method when solenoid power is not available. The use of FKM sealing material ensures compatibility with a wide range of hydraulic fluids, including HL, HLP, HETG, HEES, and HEPG. This product belongs to the product family classification of directional spool valves that are direct operated with solenoid actuation and falls under the product group ID KKDE. It has Sun TA cavity specifications and supports a nominal flow in direct acting positions. The valve's design includes ports that are configured to enable continuous loading at its rated operating pressure while allowing bidirectional flow. The Bosch Rexroth KKDER1DA/HN9V valve is characterized by its robust construction and versatile functionality. It comes in two versions: Version C for standard applications and Version K which includes a mating connector. Both versions ensure seamless integration into various hydraulic systems. The compact size and weight (0.7 kg) make it suitable for space-conscious applications without compromising on power or efficiency. In summary, the Bosch Rexroth KKDER1DA/HN9V offers reliable performance with its direct-controlled directional slide valve mechanism enhanced by solenoid actuation, capable of managing substantial pressure and flow rates in various hydraulic applications.
