FLOAT SWITCH ABZMS-35-1X/090F030S-K24

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth ABZMS-35-1X/090F030S-K24 (R901057912) is a highly precise and reliable float switch designed to monitor and control fluid levels in hydraulic systems. This float switch is an essential component for small power units of the ABSKG series, including types ABSKG-...-NG; 3; 6; and 10. It features two switching contacts with pre-determined switching points at specified millimeter levels, ensuring accurate operation within the system. Capable of handling a maximum pressure, the ABZMS-35-1X/090F030S-K24 is equipped with an electrical connector described as a Connector pole, Mx, A-coded, which facilitates easy connection to electrical circuits. The product has a specific length and operates on a supply voltage range of up to V DC. Its lightweight design does not compromise its functionality or durability. With two switching outputs as part of its output signal capabilities, this float switch can handle a variety of hydraulic fluids including HLP, HFAE, HFC, HFDR, HFDU, HETG, HEES, and HEPG. The device's sliding tubes contain two fixedly set reed contacts—a normally closed contact and a normally open contact—that are triggered by permanent magnets in the float. An optional feature includes fixedly set temperature contacts designed to monitor maximum hydraulic fluid temperatures. These are not intended for controlling temperatures but serve as a shutdown mechanism when certain temperature thresholds are reached. The function of the level switch ensures that when the oil level falls and the float reaches the designated switching points, magnetic operation occurs changing the state of the contacts. These positions are maintained until the rising oil level causes the float to pass these points again. The level switch's L point can function either as normally closed or normally open contact based on configuration requirements. In summary, Bosch Rexroth's ABZMS-35-1X/090F030S-K24 float switch offers robust performance for maintaining optimal fluid levels in hydraulic systems while also providing additional safety measures through its temperature monitoring capability.
