R900963714

PROPORTIONAL DIRECTIONAL VALVE 4WRZE25W6-220-7X/6EG24N9K31/A1D3V

Manufacturer: Bosch Rexroth

Material #: R900963714

Model : 4WRZE25W6-220-7X/6EG24N9K31/A1D3V


***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth 4WRZE25W6-220-7X/6EG24N9K31/A1D3V (R900963714) is a high-performance industrial hydraulic valve designed to provide reliable control of oil flow direction based on the hydraulic symbol W. This pilot-operated proportional directional valve is equipped with integrated electronics and is capable of handling a maximum operating pressure, with a nominal flow rate. It features external pilot oil supply and return, along with a pressure reducing valve to ensure precise operation. The valve boasts an electrical connection with a connector pole PE according to EN standards and allows for subplate mounting conforming to ISO porting patterns. The 4WRZE25W6-220-7X/6EG24N9K31/A1D3V is designed for electrical actuation with integrated electronics and includes an analog connectivity option, accepting command values in the V range. This model uses FKM seals and is compatible with a variety of hydraulic fluids including HL, HLP, HLPD, HVLP, HVLPD, HETG, HEES, HEPG, HFDU, and HFDR. Its spool valve design incorporates a concealed manual override as well as concealed auxiliary actuation for additional operational flexibility. The valve's construction consists of a pilot control valve with proportional solenoids and a main valve that includes the main control spool and centering spring. When the solenoids are de-energized, the main control spool remains in its central position due to the centering spring. Upon energizing the solenoids, the pilot control valve directs pilot oil into the pressure chamber which proportionally moves the main control spool in response to electric input signals. It's important to note that accidental activation of the manual override could lead to unintended machine movements. Additionally, due to its design principle, some internal leakage may occur over time which is inherent in these valves. The Bosch Rexroth 4WRZE25W6-220-7X/6EG24N9K31/A1D3V offers robustness and precision for various hydraulic applications requiring controlled flow direction and magnitude adjustments.

$8,102.00 USD

More are expected on August 26, 2024
  Add to Cart

Status: This product is temporarily out of stock.


Qty: Delivered as early as August 26, 2024 when ordered in

This product is eligible for factory repair.
