R900773199

DBDS10K1X/110E

Manufacturer: Bosch Rexroth

Material #: R900773199

Model : DBDS10K1X/110E


***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth DBDS10K1X/110E (R900773199) is a direct-operated seat valve designed for precise system pressure limitation. This model is a part of the DBD series of pressure relief valves, which are essential components in hydraulic systems for controlling and maintaining pressure levels. The valve consists of a sleeve, spring, poppet with damping piston for pressure ratings up to 315 bar, or ball for pressure ratings up to 630 bar, and an adjustment type mechanism that allows for stepless system pressure setting. The operation of the valve is straightforward: the spring holds the poppet or ball against the seat until the system pressure in channel P surpasses the set value. At this point, the poppet or ball lifts against the spring force, allowing hydraulic fluid to flow from channel P to channel T. The stroke of the poppet is limited by embossing to ensure consistent performance. To accommodate different operating pressures and applications, Bosch Rexroth has divided the entire pressure range into various ratings, each corresponding to a specific spring designed for a maximum operating pressure. The DBDS10K1X/110E model features a poppet seat valve suitable for applications requiring precision control within its specified rating. For ease of use and safety, the adjustment element in this model cannot be lost due to its gimbal mounting design. It remains moveable even when completely unloaded. If minimum pressure doesn't settle when unloaded, users can pull back and then screw in the adjustment element again as needed. This model offers versatility in installation and adjustment options including sleeve with hexagon and protective cap, rotary knob, hand wheel, or lockable rotary knob. It can be mounted as a screw-in cartridge valve or used with threaded connections or subplate mounting. The component series X denotes its modern design iteration with a maximum operating pressure capability of up to 315 bar.

$414.00 USD

More are expected on December 16, 2024
  Add to Cart

Status: This product is temporarily out of stock.


Qty: Delivered as early as December 16, 2024 when ordered in

This product is eligible for factory repair.
