R900769430

PRESSURE RELIEF VALVE DBDS10G1X/315E

Manufacturer: Bosch Rexroth

Material #: R900769430

Model : DBDS10G1X/315E


***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth DBDS10G1X/315E (R900769430) is a high-performance, industrial hydraulic valve designed for reliable pressure limitation to a set value. This direct-actuated valve features a mechanically actuated design with a sleeve that has both a hexagon shape and protective cap for durability and ease of use. The spool symbol P T indicates the valve's functionality, and it is capable of handling maximum pressures efficiently. Equipped with mechanical actuation, the DBDS10G1X/315E conforms to CE standards and complies with the Pressure Equipment Directive of the EU. It is designed for threaded connections and has a size that supports maximum flow rates. The valve's construction includes NBR seals suitable for HL and HLP hydraulic fluids, ensuring compatibility with standard hydraulic systems. Pressure relief valves like the DBDS10G1X/315E are essential components in hydraulic systems where they serve to prevent excessive pressure buildup by allowing fluid to flow from an over-pressurized channel P to channel T. This model consists of several parts including a sleeve, spring, poppet with damping piston (for pressure ratings up to 315 bar), or ball (for different pressure ratings), along with an adjustment type that allows for stepless system pressure setting. The valve's design ensures precise pressure adjustment across its entire operating range by dividing it into specific pressure ratings, each corresponding to a particular spring suited for the maximum operating pressures achievable within that range. For secure adjustments, the DBDS10G1X/315E features an adjustment type that prevents loss and remains movable even when completely unloaded due to its gimbal mounting. The product is versatile in application methods as it can be used as a screw-in cartridge valve for threaded connections or mounted on subplates. Users have options for adjusting pressure including sleeves with hexagon and protective cap, rotary knobs, hand wheels, or lockable rotary knobs. Its component series X denotes its robustness with an impressive maximum operating pressure capability of 315 bar.

$875.00 USD

More are expected on October 16, 2024
  Add to Cart

Status: This product is temporarily out of stock.


Qty: Delivered as early as October 16, 2024 when ordered in

This product is eligible for factory repair.
