PRESSURE REDUCING VALVE DR6DP2-5X/210YM

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth DR6DP2-5X/210YM (R900455316) is a high-performance industrial hydraulic valve designed for reliable pressure reduction to a preset value. This direct-actuated spool valve features a P A spool symbol and is capable of handling a maximum pressure with an array of ports for versatile applications. The mechanical actuation ensures precise control over the valve's operations. The DR6DP2-5X/210YM valve is primarily used to maintain and limit system pressure by allowing hydraulic fluid to flow from channel P to channel A without restriction. The secondary pressure can be adjusted via an adjustment type, providing flexibility in various hydraulic systems. With its open initial position, the valve permits free flow until the set pressure is exceeded, at which point it moves to control position to maintain constant pressure levels in channel A. Furthermore, this model incorporates internal signal and pilot oil routing from channel A, ensuring efficient operation even when external forces affect the actuator. In case of increased pressure in channel A, the control spool counters this by connecting channel A to channel TY through the control edge on the spool, discharging excess hydraulic fluid into the tank. Designed for subplate mounting with connection diagrams conforming to NFPA T.. R D SizeCETOP D and ISO standards, it offers several adjustment types including rotary knob and threaded pin options. The unit also has an optional check valve for free flow back from channel A to channel P and features a pressure gauge connection for monitoring secondary pressure. With its NBR seals, it can accommodate various hydraulic fluids like HL, HLP, HLPD, HVLP, HVLPD, and HFC. The Bosch Rexroth DR6DP2-5X/210YM is available in size X with a maximum operating pressure of bar and maximum flow rate of l/min. It stands out for its robust design and versatility in managing consistent system pressures across diverse hydraulic applications.
