BALL RUNNER BLOCK RESIST NRII KWD-035-FLS-C1-H-0

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNN. BLOCK NRII KWD-035-FLS-C1-H-0 (R200231304) is a high-precision ball runner block designed for linear motion applications that demand rigidity, accuracy, and corrosion resistance. This model features an FLS format, indicating a flanged width with a long length and standard height, ensuring compatibility with size E profiled rail systems. The runner block body and all steel components are constructed from corrosion-resistant steel in accordance with DIN EN, which makes it suitable for harsh environments. With a preload class C for low preload and an accuracy class H for high precision, this ball runner block is engineered to provide smooth motion with minimal elastic deflection. Notably, it does not include a ball chain or initial lubrication and lacks attachment elements on both left and right front reference edges. The straight lube connection is loosely attached to facilitate ease of maintenance. The product boasts an overall length of 70 mm and can be interchanged with guide rails of every accuracy level to meet various application requirements. It has been designed to maintain its performance over several years of operation without the need for frequent lubrication. The patented entry zone increases travel accuracy up to six times compared to conventional systems. Additional features include a maximum permissible ambient temperature range from -10°C to +100°C, high dynamic load capacity C, static load rating C0, dynamic torsional moment load capacity Mt, and excellent dynamic characteristics that support high load ratings in all four main loading directions. This ball runner block also accommodates minimum quantity lubrication systems with integrated reservoirs for oil lubrication. In summary, the Bosch Rexroth B.RUNN. BLOCK NRII KWD-035-FLS-C1-H-0 (R200231304) is an advanced linear motion component ideal for applications requiring durability, precision movement, and resistance to corrosive elements while maintaining exceptional dynamic performance across various industrial settings.
