BALL RUNNER BLOCK NRFG KWD-015-FKS-C0-H-0

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUN. BLOCK NRFG KWD-015-FKS-C0-H-0 (R200019314) is a high-precision ball runner block designed for linear motion applications requiring corrosion resistance and high accuracy. This model features a size 15 runner block with an FKS format, indicating a flange width, short length, and standard height configuration. The runner block body and all steel components are crafted from corrosion-resistant steel in accordance with DIN standards. The B.RUN. BLOCK NRFG KWD-015-FKS-C0-H-0 is preload-free (preload class C) and boasts a high accuracy class H, ensuring precise movement for sensitive applications. Notably absent are a ball chain, preservation, initial lubrication, and attachment elements on both the left front reference edge and the right front reference edge. The straight lube connection is loosely attached for ease of maintenance. This product has an overall length of 63.2 mm and offers interchangeability within its accuracy class, meaning it can be combined with guide rails to create customized linear motion systems. It supports long-term lubrication over several years thanks to its lube fittings with metal threads on all sides. The ball runner block provides maximum system rigidity due to its preloaded O-arrangement and allows for end-face fastening thread attachments. Its design ensures high rigidity in all load directions, which permits the use of just one runner block per rail if necessary. Additionally, it includes integrated all-around sealing for protection against contaminants. Optimized entry-zone geometry and a high number of balls reduce variation in elastic deflection while ensuring smooth and quiet operation. Attachments can be mounted from both above and below the ball runner block, adding to the versatility of this component. In summary, the Bosch Rexroth B.RUN. BLOCK NRFG KWD-015-FKS-C0-H-0 (R200019314) offers excellence in dynamic characteristics suitable for packaging industries or food industry subsectors where precision and corrosion resistance are paramount.
