LAUFROLLENWAGEN SUPER ALUMINIUM LWA-025-SKS-FN-E-0

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LR-WAGEN SUPER AL LWA-025-SKS-FN-E-0 (R190612500) is a high-performance cam roller runner block designed for precision linear motion applications. This super version runner block is part of the LR series, known for its robustness and reliability in various automation and handling tasks. The R190612500 features an aluminum body, providing a lightweight yet durable solution for linear guidance systems. Specifically, this model comes with a slimline SKS format, economic accuracy class E, and a standard load carrying capacity (FN). It has been designed without initial lubrication or preservation to give users the flexibility to apply their preferred maintenance regimen. For ease of use, it includes front lube units with low-friction seals on both the left and right reference edges, as well as lube nipples. The runner block boasts an interchangeable element that can handle high loads in all four main directions, including moments about all axes. It comes equipped with wiper and lubrication units that have large oil reservoirs on both sides to ensure consistent performance over time. The two-row angular-contact ball bearings are sealed and lubricated for life, ensuring minimal maintenance. For mounting surfaces that are not level or have alignment errors, this runner block is self-aligning to compensate for such misalignments. It can be adjusted to zero clearance using eccentric spigots. The operating temperature range is from -20°C to +80°C, accommodating various working environments. The R190612500's dynamic load capacities in the z-direction (Cz) and y-direction (Cy), as well as its static load capacities in these directions, make it suitable for a wide range of applications. Additionally, it has been designed to withstand maximum permissible dynamic and static torsional moments about the x-axis (Mx). Overall, the Bosch Rexroth LR-WAGEN SUPER AL LWA-025-SKS-FN-E-0 (R190612500) cam roller runner block is an adaptable component suitable for diverse linear motion requirements within handling and automation technology sectors.
