ROLLER RUNNER BLOCK CARBON STEEL RWA-100-FNS-C3-H-2

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth R.RUNNER BLOCK CS RWA-100-FNS-C3-H-2 (R186123310) is a roller runner block designed for high precision and rigidity in heavy machine construction applications. It is part of the CS series, made from unalloyed steel, and offers high preload (class C) with high accuracy (class H). This roller runner block is notable for its ability to handle extremely high load capacities and maintain maximum rigidity in all load directions. The design includes three additional mounting screw holes at the center for improved stability under liftoff and side loading conditions. The RWA-100-FNS-C3-H-2 does not come with a roller chain, initial lubrication, or attachment elements on the left or right front reference edges. It features straight lube connections that are loosely attached, allowing for smooth operation and minimal lubrication requirements due to its innovative channel design. The optimized return and guideways of the rollers ensure quiet running. This model has a total length of . mm and allows for limitless interchangeability with guide rails across all variants within the series. Attachments can be mounted from both above and below the runner block. The aluminum end caps size and plastic size integrated front seals come as standard, providing improved sealing for all running tracks. The product’s dynamic load capacity (C), static longitudinal moment load capacity (ML), and dynamic torsional moment load capacity (Mt) are determined based on a 100,000 m travel as per DIN ISO standards. It has a friction coefficient ranging from , with an allowable ambient temperature range from min ... max °C. Additionally, it boasts a self-aligning feature to compensate for misalignments without requiring a ball chain. With its carbon steel construction, tolerance profiled rail systems of mm , max acceleration amax , it is well-suited for various linear motion applications where precision and heavy loads are factors. The lack of initial lubrication allows users to apply their preferred type or brand post-installation.
