ROLLER GUIDE RAIL CARBON STEEL RSA-100-SNS-H-MA-SC

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth R.GUIDE RAIL CS RSA-100-SNS-H-MA-SC (R183526362) is a high-precision roller guide rail designed for robust performance in demanding applications. This guide rail is part of the SNS series, which features a slim width, normal length, and standard height, offering a compact and efficient design for various linear motion needs. Manufactured from carbon steel CS, it ensures durability and long service life. The RSA-100-SNS-H-MA-SC model boasts high accuracy class, making it suitable for applications that require precise positioning and smooth operation. The guide rail comes with a bolting from above fastener option (MA), allowing for easy installation from the top side. It includes a cover strip made from corrosion-resistant spring steel according to DIN EN standards, which protects the rail and extends its lifespan. Additionally, this model has protective caps that safeguard the ends of the rail during use. This two-piece standard version rail features hardened raceways that are smoothened on all sides to enhance movement quality and reduce wear on moving components. Its unique design allows one cover to fit all bore holes, thereby saving time and reducing costs during assembly or maintenance. The cover strip is also easy to mount securely, thanks to its clip-on design with a locking mechanism. With maximum rigidity in all load directions, this roller guide rail can handle high torque loads efficiently. The permissible ambient temperature range for operation is between -10°C to +80°C; however, for lower temperatures, consultation with Bosch Rexroth is recommended. The RSA-100-SNS-H-MA-SC model has a weight of 4.5 kg/m and supports a maximum length (Lmax) of 4000 mm for the guide rails. It's designed with pitch T guide rails for optimal spacing and performance in various linear motion setups. The product group ID indicates that this model belongs to an accuracy class H (highly accurate), ensuring top-tier precision in applications where it's employed.
