ROLLER RUNNER BLOCK CARBON STEEL RWA-025-SNH-C2-P-2

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth R.RUNNER BLOCK CS RWA-025-SNH-C2-P-2 (R182122216) is a high-precision roller runner block designed for linear guidance and motion. This component is part of Bosch Rexroth's linear guide system and is characterized by its slimline width, normal length, and high height format (SNH). The runner block body is constructed from unalloyed steel CS, ensuring durability and robustness in various applications. It boasts a medium preload class C, which provides an average preload to the system for optimized performance. The RWA-025-SNH-C2-P-2 model offers precision with an accuracy class P, signifying its suitability for applications requiring high accuracy in movement. It does not include a roller chain and comes preserved without initial lubrication or any attachment elements on the left or right front reference edge. Additionally, there are no lube connections attached to this runner block. This model has a standard overall length and is interchangeable with guide rails of every accuracy level within the system. The product features a dynamic load capacity C based on a 100,000 m travel as per DIN ISO norms, with the ability to multiply values by 1.26 for comparison when only 50,000 m are stipulated. Designed to self-align for compensation of misalignments without self-alignment ball chain, it also has a static load rating C0 and dynamic torsional moment load capacity Mt that caters to various operational demands. The permissible ambient temperature range for this component extends from minimum to maximum degrees Celsius as specified in the detailed technical data. It's also important to note that this runner block can achieve speeds up to 5 m/s although maximum permissible speed may vary depending on application requirements; higher speeds limit service life due to increased stress on plastic parts. For optimal performance, there must be preload even during operation under load. The Bosch Rexroth R.RUNNER BLOCK CS RWA-025-SNH-C2-P-2 (R182122216) is well-suited for oil and grease lubrication from above and represents a high-quality choice for those seeking reliable linear motion components in their machinery or equipment configurations.
