BALL RUNNER BLOCK CARBON STEEL KWD-035-SKS-C1-N-1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-035-SKS-C1-N-1 (R16663142Y) is a high-precision ball runner block designed for linear motion applications. It features a slimline width, short length, and standard height format (SKS), making it suitable for restricted space conditions in both longitudinal and transverse directions. The runner block body is crafted from unalloyed steel CS, ensuring durability and robust performance. This model offers low preload (Preload class C) and standard accuracy (Accuracy class N), coupled with a ball chain that contributes to smooth travel behavior and reduced noise levels. The design incorporates optimized entry-zone geometry and a high number of balls to minimize variation in elastic deflection, which enhances the system's dynamic characteristics. The B.RUNNER BLOCK CS comes pre-lubricated with roller bearing grease Dynalub for long-term maintenance-free operation and includes an integrated all-around sealing system to protect against contaminants. Additionally, it features a minimum quantity lubrication system with an oil reservoir for optimal lubrication over time. Attachments can be mounted from above on the ball runner block, which offers high load ratings in all four main loading directions. Its end-face fastening thread allows for various attachments, promoting versatility across applications. This model is compatible with all SN/SNO ball guide rails within the same accuracy class, boasting limitless interchangeability. The overall length of the runner block is specified as . mm, while the height of the runner block is . mm. The dynamic load capacity C and static longitudinal moment load capacity ML are determined based on a 100 km travel as per DIN ISO standards. In terms of environmental conditions, this unit can operate within an ambient temperature range of min ... max °C but should be consulted for use at negative temperatures. The friction coefficient ranges from , indicating efficient motion with minimal resistance. In summary, the Bosch Rexroth B.RUNNER BLOCK CS KWD-035-SKS-C1-N-1 (R16663142Y) is an advanced linear motion component ideal for various applications requiring precision movement within confined spaces while maintaining high performance and reliability over extended periods.
