BALL RUNNER BLOCK CARBON STEEL KWC-020-FKN-C1-N-2

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWC-020-FKN-C1-N-2 (R166381410) is a state-of-the-art ball runner block designed for linear motion applications where space constraints are a critical factor. This product is part of the Ball Rail Systems and is specifically engineered to provide maximum precision and efficiency in linear guidance. The runner block body is constructed from unalloyed steel CS, ensuring durability and robustness for long-term use. It features a low preload (Preload class C) and standard accuracy (Accuracy class N), making it suitable for various applications without the need for a ball chain. This Bosch Rexroth runner block boasts an optimized entry zone geometry that significantly enhances travel accuracy by up to six times, reducing frictional oscillations and maintaining a low friction force level, especially when subjected to external loads. The product's design allows for long-term lubrication over several years, with angular lube nipples loosely attached for easy maintenance. Additionally, it offers end-face fastening threads compatible with all attachments and can be utilized on all SNS/SNO ball guide rails. The B.RUNNER BLOCK CS KWC-020-FKN-C1-N-2 features integrated all-around sealing to protect against contamination from dirt, chips, or coolants, which could otherwise reduce its service life. For those requiring precise movement control, there is an optional integrated, inductive, and wear-free measuring system available. Its dynamic load capacity C and static load capacity C0 are determined based on DIN ISO standards ensuring reliable performance under various conditions. The product's design also includes self-aligning capabilities to compensate for any misalignments during installation or operation. In summary, the Bosch Rexroth B.RUNNER BLOCK CS KWC-020-FKN-C1-N-2 (R166381410) offers exceptional precision and durability for linear motion systems with restricted space availability. Its advanced features ensure reduced frictional forces, high travel accuracy, and compatibility with a wide range of guide rails and attachments – making it an ideal choice for demanding industrial applications.
