R16532232Y

BALL RUNNER BLOCK CARBON STEEL KWD-025-FLS-C2-H-1

Manufacturer: Bosch Rexroth

Material #: R16532232Y

Model : B.RUNNER BLOCK CS KWD-025-FLS-C2-H-1


***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-025-FLS-C2-H-1 (R16532232Y) is a high-precision ball runner block designed for linear motion applications requiring exceptional rigidity and accuracy. This runner block features a size 25 profile, with a flanged, long, and standard height (FLS) format. The body of the runner block is constructed from unalloyed steel CS, ensuring durability and strength. It offers medium preload (class C) and high accuracy (class H), making it suitable for applications with demanding rigidity requirements. The B.RUNNER BLOCK CS KWD-025-FLS-C2-H-1 is equipped with a ball chain that contributes to low noise levels and smooth travel behavior. Its design includes integrated all-around sealing to protect against contaminants, increasing longevity and reliability. The product also boasts a dynamic load capacity C, static longitudinal moment load capacity ML, and dynamic torsional moment load capacity Mt. For ease of installation and maintenance, the runner block provides end-face fastening threads for various attachments and is pre-lubricated at the factory for immediate use. It can be mounted on all SNS/SNO ball guide rails without compromising load ratings in any of the four main loading directions. Additional features include two extra mounting screw holes at the center for improved rigidity under side loading conditions, an optional integrated measuring system for precise motion control, and the ability to accommodate attachments from both above and below. This Bosch Rexroth ball runner block stands out for its combination of high torque capacity, different preload classes available to suit specific application needs, long-term lubrication capabilities over several years with accessible lube fittings featuring metal threads on all sides, as well as its compatibility with various seals like SS (Standard Seal), LS (Low-friction Seal), DS (Double-lip Seal), front seal options for fine dirt or metal particle environments, FKM seal for extreme conditions, and cover plate wipers for coarse dirt or chips.

$274.96 USD

More are expected on December 16, 2024
  Add to Cart

Status: This product is temporarily out of stock.


Qty: Delivered as early as December 16, 2024 when ordered in
