BALL RUNNER BLOCK CARBON STEEL KWD-015-FLS-C3-UP-1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-015-FLS-C3-UP-1 (R16531392Z) is a high-precision ball runner block designed for use in linear motion systems where ultra precision and high rigidity are required. This runner block features a steel CS body, size N with an FLS format which denotes a flange width, long length, and standard height. Its preload class C indicates a high preload for increased support and reduced play, enhancing system stiffness. With an accuracy class UP (ultra precision), this component ensures maximum travel accuracy, which is critical for applications demanding the highest levels of precision. The B.RUNNER BLOCK does not incorporate a ball chain, but it comes with initial lubrication and preservation to maintain performance over time. The product uses Roller bearing grease Dynalub for smooth operation. The overall length of the runner block is . mm, and it can be combined with guide rails of every accuracy level to meet various application needs. It offers reduced frictional oscillations and low friction force levels even under external loads, resulting in excellent dynamic characteristics suitable for demanding rigidity requirements. This runner block is designed without attachment elements on either front reference edge but includes straight lube connections loosely attached. It also features an end-face fastening thread for all attachments and integrated all-around sealing to protect against contaminants. The high torque load capacity and the ability to mount attachments from above or below provide versatility in design configurations. It is compatible with all SN/SNO ball guide rails, ensuring the same high load ratings in all four main loading directions. Additionally, the B.RUNNER BLOCK's design allows for improved rigidity under liftoff and side loading conditions due to two additional mounting screw holes at the center of the unit. The product's unique construction permits applications using just one runner block per rail while still achieving maximum system rigidity due to its preloaded O-arrangement. Optional features include an integrated inductive and wear-free measuring system for precise feedback on position. In summary, the Bosch Rexroth B.RUNNER BLOCK CS KWD-015-FLS-C3-UP-1 (R16531392Z) is a versatile, ultra-high precision component ideal for sophisticated linear motion applications requiring exceptional accuracy and rigidity.
