BALL RUNNER BLOCK CARBON STEEL KWD-030-SLS-C2-H-1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-030-SLS-C2-H-1 (R162372322) is a premium ball runner block designed for linear motion applications requiring high precision and durability. This runner block boasts an SLS format, which stands for slimline width, long length, and standard height, making it suitable for applications with limited space in the transverse direction. The body of the runner block is crafted from unalloyed steel CS for robustness. It features a medium preload class C and a high accuracy class H, ensuring precise movement and alignment. The ball chain included with the runner block contributes to low noise levels and optimal travel behavior. For maintenance ease, it comes with initial lubrication and preservation, utilizing Roller bearing grease Dynalub. The B.RUNNER BLOCK CS has an overall length of . mm and supports high loads from all four main loading directions due to its optimized entry zone geometry. It also boasts a high torque load capacity. Designed for interchangeability, it can be combined with any guide rail within each accuracy class. Attachments can be mounted from above thanks to the end-face fastening thread while integrated all-around sealing protects against contaminants. This model also features a minimum quantity lubrication system with an integrated reservoir for oil lubrication, ensuring long-term performance without frequent maintenance. It's compatible with all SN/SNO ball guide rails and exhibits excellent dynamic characteristics due to its design that allows for minimal variation in elastic deflection. The permissible ambient temperature range for this ball runner block spans from min ... max °C (admissible for short periods), ensuring reliable operation across various environments. With its dynamic load capacity C based on DIN ISO standards, this product is engineered to meet stringent performance criteria in demanding applications. In summary, the Bosch Rexroth B.RUNNER BLOCK CS KWD-030-SLS-C2-H-1 (R162372322) is a versatile and highly precise component suitable for linear motion systems where space is at a premium and high loads are expected. Its comprehensive design ensures longevity, consistent performance, and compatibility with various attachments and guide rails.
