BALL RUNNER BLOCK CARBON STEEL KWD-025-SLS-C0-H-1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-025-SLS-C0-H-1 (R162329320) is a high-precision ball runner block designed to offer superior performance in linear motion applications. This product is part of the Ball Rail Systems and falls under the category of Ball Runner Blocks. It features a slimline width, long length, and standard height (SLS format), constructed from unalloyed steel CS for robustness. The runner block is notable for its high accuracy class H and is preload-free, belonging to preload class C. The B.RUNNER BLOCK CS KWD-025-SLS-C0-H-1 does not include a ball chain but comes with initial lubrication and preservation, utilizing roller bearing grease Dynalub for smooth operation. It boasts an overall length of . mm and supports attachments that can be mounted from above without the need for left or right front reference edge attachment elements. This model also features a straight lube connection that is loosely attached. This runner block's design enables it to handle very high loads efficiently with consistent load ratings in all four main loading directions. It allows long-term lubrication over several years and offers limitless interchangeability within each accuracy class across all ball guide rail systems. The optimized entry-zone geometry along with a high number of balls reduces variation in elastic deflection, ensuring high torque load capacity. For sealing, the B.RUNNER BLOCK CS comes equipped with integrated all-around sealing to protect against contaminants and includes a minimum quantity lubrication system with an oil reservoir. It also provides end-face fastening threads for various attachments and can be utilized on all SN/SNO Ball Guide Rails. In summary, the Bosch Rexroth B.RUNNER BLOCK CS KWD-025-SLS-C0-H-1 (R162329320) delivers excellent dynamic characteristics suitable for applications requiring precision linear movement, especially where space is restricted in the transverse direction or when dealing with significant loads. Its design ensures minimal maintenance while offering flexibility through interchangeability and compatibility with various guide rails within its accuracy class.
