BALL RUNNER BLOCK CARBON STEEL KWD-015-SNS-C3-X-1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-015-SNS-C3-X-1 (R162213822) is a high-precision ball runner block designed for linear motion applications requiring exacting standards of accuracy and preload. This model features a slimline width, normal length, and standard height format (SNS), making it suitable for situations where space is limited in the transverse direction. Constructed from unalloyed steel CS, the runner block body ensures robustness and durability. With a high preload class C and extra precision accuracy class XP, this runner block delivers exceptional performance. It includes an integrated ball chain which contributes to low noise operation and smooth travel behavior. The product comes pre-lubricated with Dynalub grease, ensuring long-term lubrication over several years without the need for frequent maintenance. This runner block boasts impressive dynamic characteristics, including high load ratings in all four main directions of loading and the ability to handle high torque loads efficiently. Its optimized entry-zone geometry along with a significant number of balls helps minimize variation in elastic deflection during use. Additionally, it features integrated all-round sealing that protects against contaminants while maintaining ease of movement. The minimum quantity lubrication system with an integrated reservoir allows for oil lubrication when necessary. Attachments can be easily mounted from above thanks to the end-face fastening thread provided on the runner block. The B.RUNNER BLOCK CS KWD-015-SNS-C3-X-1 is fully interchangeable within its accuracy class across all ball guide rail systems offered by Bosch Rexroth, including SN/SNO types. This interchangeability coupled with various preload classes makes it a versatile choice for diverse application requirements. Designed to perform reliably within a temperature range of -10°C to +100°C (with short-time admissibility), this linear guide component offers excellent dynamic load capacity and static torsional moment load capacity, ensuring stable operation under demanding conditions.
