BALL GUIDE RAIL CARBON STEEL KSA-055-SNS-H-MB-00

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.GUIDE RAIL CS (R160750331) is a high-precision ball guide rail system designed for applications requiring maximum rigidity and high torque load capacity. This slimline SNS-format guide rail is made from carbon steel CS and is characterized by its one-piece construction, ensuring a robust and reliable guidance system. With a high accuracy class, it allows for greater side loads and provides the best sealing action of end seals without the need for a cover strip. This model, specifically designed for mounting from below through fastener MB (bolting from below), facilitates an easy and secure installation process. It is ideal for scenarios where space conservation at the rail ends is critical. The guide rail's dimensions are tailored to fit T profiled rail systems, accommodating various industrial applications. The B.GUIDE RAIL CS boasts an impressive permissible ambient temperature range, although it should be noted that special considerations must be made for operations at negative temperatures. The product's mass and pitch are optimized to balance weight and structural integrity, ensuring efficient performance across its maximum length. Additionally, this ball rail system follows the DIN standard selection criteria for linear guides, making it compatible with widely accepted engineering practices. Its design allows for straightforward calculations of recommended rail lengths based on the number of holes and pitch of the guide rail. Overall, the Bosch Rexroth B.GUIDE RAIL CS offers a durable solution for linear motion requirements in various applications where precise guidance and high load capacities are essential.
