BALL GUIDE RAIL CARBON STEEL KSA-015-SNS-U-MB-00

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.GUIDE RAIL CS (R160710932) is a high-precision ball guide rail system designed to provide maximum rigidity and load capacity in various applications. This particular model, part of the SNS size format, features a slimline width, normal length, and standard height, making it versatile for integration into a range of equipment where space may be limited. The guide rail is crafted from carbon steel (CS), ensuring durability and strength. This ultra-precision rail is classified under the accuracy class UP and is engineered to allow greater side loads, which makes it suitable for scenarios demanding high torque load capacity without compromising precision. It comes as a two-piece section without a cover strip, which simplifies installation while still offering excellent sealing action from the end seals. The B.GUIDE RAIL CS is designed for bolting from below (fastener MB), allowing for a cleaner assembly with no extra space needed at the rail ends. The product can withstand permissible ambient temperatures ranging from minimum to maximum degrees Celsius; however, for operation at negative temperatures or beyond specified limits, consultation with Bosch Rexroth is advised. With its T-profiled rail systems and multipart construction, this guide rail ensures no sacrifice in performance across all load directions. It has been developed following DIN standards for linear guides selection, confirming its compatibility with industry norms. The recommended rail length formula provided ensures optimal performance when determining the necessary size during installation. Overall, the Bosch Rexroth B.GUIDE RAIL CS offers an exceptional solution for those requiring precise linear motion control in their machinery or automation systems.
