BALL GUIDE RAIL CARBON STEEL KSA-020-SNS-U-MA-AB

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.GUIDE RAIL CS (R160586932) is a ball guide rail system that offers exceptional precision and durability, designed specifically for applications that demand high levels of accuracy and rigidity. This model features a slimline width, standard height, and normal length format (SNS), with the guide rail constructed from high-quality carbon steel (CS). The fastener type MA indicates that it is suitable for bolting from above, which simplifies installation. It includes a cover strip (AB) made from corrosion-resistant spring steel compliant with DIN EN standards, along with screw-down plastic protective caps for the threaded holes on the end faces. The B.GUIDE RAIL CS is engineered to withstand harsh environments and provides maximum rigidity in all load directions as well as a high torque load capacity. It is designed as a two-piece rail system, ensuring ease of handling and installation. This product belongs to Bosch Rexroth's ultra precision accuracy class (UP), guaranteeing superior guidance and reduced system play. With its compact strip clamp design, this guide rail system can accommodate a maximum length (Lmax) of up to 2 meters. It operates efficiently within a permissible ambient temperature range of -10°C to +80°C but can endure higher temperatures for short periods. For use in colder conditions or beyond the specified temperature range, consultation with the manufacturer is recommended. The B.GUIDE RAIL CS has been created to fit seamlessly into size T profiled rail systems and comes with a weight specification of 2.3 kg/m. The number of holes and their pitch are tailored for size N profiled rail systems, ensuring compatibility and ease of integration into various linear motion setups. This ball rail system is part of Productgroup ID 'Runner block or guide rail' category and is an ideal choice for those seeking a reliable linear guiding solution with ultra-precise movement capabilities.
