BALL GUIDE RAIL CARBON STEEL KSA-030-SNS-N-MA-BS

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.GUIDE RAIL CS (R160573431) is a high-precision ball guide rail system designed to deliver superior performance in demanding applications. This robust guide rail is part of the linear guide product family and is engineered to provide top rigidity in all load directions, with an exceptional high torque load capacity. It features a slimline width (Format SNS), standard height, and normal length, made from durable carbon steel CS, ensuring longevity even in harsh environments. The B.GUIDE RAIL CS is equipped with a bolting fastener from above (Fastener MA), which facilitates easy and secure mounting. It also comes with a cover strip and strip clamp (Cover BS) that are made of corrosion-resistant spring steel according to DIN EN standards, offering additional protection and extending the rail's service life. The cover strip design simplifies installation as it requires only one cover for all boreholes, thereby saving time and reducing costs. This one-piece guide rail boasts an accuracy class standard and can support a permissible ambient temperature range from minimum to maximum degrees Celsius (with short-term admissibility). For applications requiring operation at negative temperatures, consultation with Bosch Rexroth is recommended. The B.GUIDE RAIL CS's design includes aluminum strip clamps without threaded holes on end faces, ensuring maximum rigidity without compromising ease of installation. The rail system's weight and dimensions are optimized for its nominal size, while the pitch T of the guide rail ensures compatibility with various runner blocks or guide rails within the same size category. With its proven track record for precision and durability, the Bosch Rexroth B.GUIDE RAIL CS provides reliable guidance for linear motion components across various applications where robustness and precision are critical.
