BALL GUIDE RAIL CARBON STEEL KSA-045-SNS-H-MA-BS

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.GUIDE RAIL CS (R160543361) is a high-precision ball guide rail designed for robust performance in harsh environments. With an SNS format indicating a slimline width, normal length, and standard height, this one-piece guide rail is constructed from carbon steel CS, ensuring durability and strength. It features a high accuracy class and is equipped with a fastener MA for bolting from above, making installation straightforward and secure. The guide rail also comes with a cover strip made of corrosion-resistant spring steel conforming to DIN EN standards, along with aluminum strip clamps that do not require threaded holes on the end faces. This design offers maximum rigidity in all load directions and an impressive torque load capacity. The cover strip system simplifies maintenance by providing a single cover for all mounting holes, eliminating the need for an end-face hole for the strip clamp. This product's permissible ambient temperature range extends from -20°C to +80°C, although it can withstand higher temperatures for short periods; consultation is recommended for use at negative temperatures. The maximum length of the guide rail (Lmax) can be calculated using the recommended formula involving the number of holes (nB) and pitch (T). The mass of the guide rail is 2.9 kg/m, ensuring that it remains lightweight while maintaining structural integrity. Designed primarily as part of Bosch Rexroth's linear guide systems, this ball rail system offers easy mounting and security during installation. Its proven cover strip design not only enhances protection against environmental factors but also reduces time and costs associated with maintenance. Ideal for applications requiring precise linear motion control, this ball guide rail system stands out for its reliability and ease of use in demanding operational conditions.
