BALL GUIDE RAIL CARBON STEEL KSA-045-SNS-H-MA-AK

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.GUIDE RAIL CS (R160540332) is a high-precision ball guide rail designed for linear motion applications requiring maximum rigidity and high torque load capacity. This product is part of the ball rail systems and adheres to DIN standards for linear guides. The guide rail is constructed from carbon steel (CS), ensuring durability and strength, while the slimline SNS format offers a compact width with standard height and normal length, making it suitable for various installation environments. With an accuracy class designated as high, this two-piece rail system provides exceptional precision in movement. The fastening method MA allows for bolting from above, simplifying the installation process, and it comes equipped with plastic caps (cover AK) to protect the mounting holes. The guide rail's design eliminates the need for extra space at the ends of the rail, further contributing to its versatile application potential. This model has been engineered to withstand permissible ambient temperatures ranging from -10°C to +80°C for standard operation, with short-term excursions permissible outside this range. For applications involving negative temperatures, consultation with Bosch Rexroth is advised. The B.GUIDE RAIL CS offers a maximum length (Lmax) of up to 2 meters for profiled rail systems size T and supports a weight of 0.7 kg/m. Its multipart structure allows for flexibility in length according to specific requirements, using the recommended formula L = nB * T + 60 mm for determining optimal rail length. This guide rail system is ideal for scenarios where precise linear guidance is critical. With its robust construction and high accuracy, it ensures reliable performance in various applications without compromising on space or installation ease.
