BALL GUIDE RAIL CARBON STEEL KSA-035-SNS-S-MA-AB

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.GUIDE RAIL CS (R160536161) is a high-precision ball guide rail system designed for superior performance in demanding applications. This guide rail is crafted from carbon steel (CS), ensuring durability and resistance to harsh environments. It boasts a slimline width, standard height, and normal length configuration, classified under the SNS size format. The B.GUIDE RAIL CS offers exceptional accuracy with its super precision class, making it suitable for applications requiring exact motion control. It comes as a one-piece rail, eliminating the need for multiple sections and ensuring maximum rigidity in all load directions. The guide rail also has an impressive torque load capacity. Installation is made easy with fastener MA, allowing for bolting from above. The product includes a cover strip made of corrosion-resistant spring steel conforming to DIN EN standards and plastic protective caps with threaded holes on the end faces for added protection. This model is specifically designed to withstand a permissible ambient temperature range from a minimum to maximum as specified in the product details. For extreme temperature conditions or operation at negative temperatures, consultation with Bosch Rexroth is recommended. The B.GUIDE RAIL CS can accommodate maximum lengths up to Lmax and maintains its structural integrity within the permissible temperature range provided. Its mass per meter is detailed in the specifications along with the number of mounting holes and their pitch. This Bosch Rexroth guide rail system conforms to DIN standards for linear guides selection and promises ease of maintenance with its single cover design for all holes, facilitating mounting from above. Its compact strip clamp and cover strip enhance its application versatility while maintaining high performance in challenging industrial settings.
