BALL GUIDE RAIL CARBON STEEL KSA-015-SNS-P-MA-BS

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.GUIDE RAIL CS (R160513231) is a high-precision ball guide rail system designed for applications requiring maximum rigidity and torque capacity in all load directions. This robust guide rail is part of the linear ball rail systems, which are characterized by their slimline width, standard height, and normal length (SNS format). It is manufactured from carbon steel CS, ensuring durability and resistance to harsh environments. This particular model features a bolting from above fastener system (MA), allowing for secure mounting. It also includes a cover strip made of corrosion-resistant spring steel compliant with DIN EN standards and aluminum strip clamps that do not require threaded holes on end faces. The cover strip design simplifies installation as it can be clipped on securely without the need for an end-face hole in the strip clamp. The B.GUIDE RAIL CS offers a one-piece construction with precision accuracy class P, indicating its suitability for applications where precise guidance is crucial. The guide rail can withstand permissible ambient temperatures ranging from -10°C to +100°C for short periods, although consultation is recommended for operations at negative temperatures. With a mass of 9 kg/m and a maximum length (Lmax) of 1 meter, this guide rail system ensures optimal performance in various applications. The pitch T of the guide rail holes is designed to accommodate size N profiled rail systems with a tolerance profiled rail system of 15 mm. For optimal use, the recommended rail length formula L = nB * T + 60 mm should be followed. In summary, the Bosch Rexroth B.GUIDE RAIL CS offers exceptional precision and robustness for linear motion applications where high rigidity and torque capacity are essential. Its user-friendly design with an efficient cover system makes it an ideal choice for easy mounting and long-term performance in demanding operational conditions.
