BALL SCREW 20X5RX3 (T7)

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth BALL SCREW 20X5RX3 (R151111700) is a high-precision ball screw assembly designed for linear motion applications. With its nominal diameter of 20mm and a lead of 5mm, this right-hand thread ball screw ensures accurate and efficient movement. The ball diameter Dw is meticulously crafted to fit the screw's specifications, while the T7 tolerance grade indicates the product's high precision level. This ball screw is part of Bosch Rexroth's Precision Screw product group and is specifically categorized as a Precision Spindle. The R151111700 has a maximum operating temperature range, capable of continuous operation at temperatures up to 80°C, with temporary peaks permissible up to 100°C, measured on the outer shell of the nut. Its minimum operating temperature complements this range, ensuring reliable performance in varying environmental conditions. With its robust design, the BALL SCREW 20X5RX3 can handle significant loads and speeds while maintaining accuracy and longevity. The assembly's mass is calculated at kg/m, which contributes to its moment of inertia Js value – essential for understanding the dynamics during operation. This particular model is characterized by its right-hand direction lead and comes as a complete ball screw assembly which includes both nut and screw components. Its maximum length Lmax ensures that it can accommodate various application lengths without compromising on performance. Overall, the Bosch Rexroth BALL SCREW 20X5RX3 (R151111700) represents an optimal solution for applications requiring precise linear motion control with high reliability under varying temperature conditions.
