This product is not available. CLICK HERE to create a support ticket for us to locate your part or a suitable replacement
| Lightweight precision housing (aluminum) |
| standard linear bushing |
| Secured by grooved taper pin |
| External seals |
| No lube port |
| Data Sheet | Download Data Sheet |
| Manual | Download Manual |
| Manual | Download Manual |
| Manual | Download Manual |
| Manual | Download Manual |
| Manual | Download Manual |
| Size V | 12 |
| Footnote shaft radial clearance h6 | Clamped (fastened). |
| Series | Standard (metal) |
| Footnote friction force FR | Frictional drags generated by linear bushings with integrated wiper seals on two sides when not under radial load. The frictional drags depend on speed and lubrication. |
| Size E1 | 50 |
| Footnote dynamic load capacity C | The load capacities apply for the main direction of loading. |
| Size H | 50 |
| Max. acceleration amax | 50 |
| Permissible ambient temperature | -10 °C ... +80 °C |
| Outer diameter D | 75 |
| Breakaway force | 40 |
| Size H4 | 45 |
| Maximum permissible linear speed vmax | 2 |
| Size D | 75 |
| Footnote static load capacity C0 | The load capacities apply for the main direction of loading. |
| Size N1 | 78 |
| Static load rating C0 | 6900 |
| Size M | 38 |
| Friction force | 14 |
| Size A | 127 |
| Productgroup ID | 17 |
| Size N2 | 30 |
| Size W | 21 |
| Size E3 | 70 |
| Permissible ambient temperature (max) | |
| Size E2 | 62 |
| Size E4 | 85 |
| Size SW | 5 |
| Permissible ambient temperature (min) | |
| Size S | 17.5 |
| Shaft diameter d | 50 |
| Linear guide type | Linear bushing and shaft |
| Filter for linear bushings and shafts | Linear sets with linear bushings |
| Format of linear bushings | S – With side opening |
| Dynamic load capacity C | 8470 |
| Size L | 113 |
| Size S2 | 12 |
| Weight | 3.723 |
| Size D1 with tolerance | |
| Size H1 | 115 |
