LINEAR-SET LSAE-B-20-DD

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSAE-B-20-DD (R103682020) is a high-precision linear motion set designed for various applications requiring accurate and smooth movement. This linear set features a lightweight precision housing made of aluminum and includes a super linear bushing B, which is characterized by its lack of self-alignment capabilities. The bushing is externally sealed and relubricatable, ensuring long-term durability and ease of maintenance. Equipped with two integrated wiper seals on each side, the LINEAR-SET LSAE-B-20-DD minimizes frictional drags even when not under radial load. The frictional drags vary depending on speed and lubrication conditions. With a shaft diameter of 20mm, this linear set is designed to accommodate moderate to heavy loads efficiently while maintaining precise motion control. The product has an impressive dynamic load capacity and static load rating, ensuring it can handle the demands of various applications without compromising performance. The maximum permissible linear speed indicates that the system can operate at high speeds—up to 5 m/s in some cases—though service life may be limited due to increased wear on plastic parts. This Bosch Rexroth linear set operates effectively within a wide range of ambient temperatures, from -20°C up to +80°C, allowing for versatility in different working environments. The outer diameter of the housing corresponds with the size H standard while maintaining a compact form factor. The LINEAR-SET LSAE-B-20-DD comes pre-set to zero clearance or preloaded guides, featuring an adjusting screw for radial clearance adjustments as per application requirements. Its design ensures that it can be easily integrated into various systems where precise linear guidance is crucial. With its robust construction and reliable performance characteristics, this Bosch Rexroth Linear Set is an essential component for applications requiring exacting linear motion control.
